16.9 Import and Export Settings

16.9.1 Export Settings

The export functionality allows you to save the current DICOM Viewer settings in a file. To export settings:

1. Select the Options menu and the Export settings item. The save file dialog box will pop up.

2. Select the location to save the settings file to and enter the file name.

3. Click Save to save the settings file or Cancel to cancel the actions.

16.9.2 Import Settings

The import functionality allows you to apply the settings specified earlier and saved in a file. To import settings:

1. Select the Options menu and the Import settings item. The DICOM Viewer will request confirmation for this action because all the current settings will be lost after the import. Click Yes to continue or No to cancel the import.

2. If you click Yes, the settings file selection dialog box will pop up. Select the needed file.

3. To import the settings, click Open. The DICOM Viewer will be restarted, and the settings will be applied. To cancel the import, click Cancel.

16.9.3 Import CLUTs

The CLUTs import option provides an opportunity to use customized CLUTs (e.g. CLUTs created by other users or CLUTs from previous DICOM Viewer versions).

CLUTs are saved in vt_config.xml file.

To import CLUTs, copy the vt_config.xml file to the Configs folder. The location of the Configs folder depends on the operating system (see Section Service files).

For example, a user named Smith working on Windows will find the CLUTs for Inobitec DICOM Viewer Pro 2.7.0 in the following folder: C:\Users\Smith\AppData\Local \Inobitec \Inobitec DICOM Viewer Professional Edition 2.7.0\Configs
